The 4T spider crawler crane is a compact yet powerful lifting solution designed to meet the demands of modern industries. Widely used in construction, transportation, manufacturing, and maintenance sectors, this mini crane offers outstanding flexibility, strong lifting performance, and excellent adaptability to complex working environments.
This spider crawler crane is especially suitable for tasks such as glass curtain wall installation, petrochemical pipeline handling, railway construction, workshop equipment maintenance, and municipal engineering projects. Thanks to its compact structure, it can easily operate in confined spaces like tunnels, narrow streets, and indoor workshops where traditional cranes cannot reach.
One of the key advantages of the 4T spider crawler crane is its compact and lightweight design. The machine can be transported conveniently using standard trucks or containers without requiring special transport vehicles, significantly reducing logistics costs. At the same time, the crawler chassis ensures excellent stability and mobility across various terrains, including rough mountain roads, muddy construction sites, and soft sand areas. Its low ground pressure design also protects delicate surfaces from damage.
| Model No. | ESC-15 | ESC-20 | ESC-30 | ESC-50 | ESC-80 | ESC-100 | ESC-120 | ESC-160 | |
| Load Capacity | 1.5tons | 2 tons | 3 tons | 5 tons | 8 tons | 10 tons | 12 ton | 16 tons | |
| Lifting Height | 5.8m | 6.8m | 10.05m | 16m | 18m | 21m | 24.5m | 24.5m | |
| Max Operating Radius | 6m×0.4t | 6m×0.4t | 8.6m×0.4t | 15.3m×0.4t | 16.5m×0.35t | 20m×0.2t | 23m×0.2t | 23m×0.2t | |
| Walking device | Walking Mode | Hydraulic motor drive, two speed | |||||||
| Walking Speed | 0-2.5km/h | 0-2.5km/h | 0-2.5km/h | 0-5.5km/h | 0-5.5km/h | 0-5.5km/h | 0-5.5km/h | 0-5.5km/h | |
| Climbing Ability | 20°(36%) | ||||||||
| Engine | Start Mode | Electric start | |||||||
| Startup Tempt. | -5°C~40°C | ||||||||
| Engine | AC Electric + Diesel Dual Power | ||||||||
| Battery Capacity | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | 12V/45Ah | |
| Weight(KG) | 1200kg | 1500kg | 2600kg | 6300kg | 7600kg | 8200kg | 11500kg | 13500kg | |
| Vehicle Size(e( L*W*H) | 2.1*0.6*1.4m | 2.2* 0.95*1.65m | 3.4*0.95*1.65m | 4.5 *1.4 * 2.1m | 4.95*1.6*2.25m | 5.5*1.6*2.25m | 5.7*1.8* 2.4m | 6.5*2*2.4m | |
| 20ft Container Loading Qty | 5 sets | 3 sets | 2 sets | 1 set | 1 set | 1set | 1 set | 1set | |
Despite its small size, this crane delivers impressive lifting performance. With a maximum working range of up to 10.8 meters and a 360-degree rotating boom, the 4T spider crawler crane provides a wide operating area and precise load positioning. The hydraulic telescopic boom allows flexible extension, making it suitable for a variety of lifting tasks.
The crane is equipped with full hydraulic outriggers that can be precisely adjusted to ensure stable support on uneven ground. This feature enhances safety and operational reliability, especially in challenging job site conditions. In addition, users can choose between remote control and manual control modes. Remote operation improves safety by allowing operators to work from a distance, while manual control offers greater precision for delicate tasks.
To meet different working requirements, the 4T spider crawler crane offers multiple power options. Customers can select a diesel engine for outdoor applications requiring long endurance, or an electric motor for indoor environments where low noise and zero emissions are essential. Hybrid power solutions are also available for maximum flexibility.
In terms of service, the crane comes with a 1-year warranty (excluding wearing parts) and comprehensive after-sales support. A professional technical team is available 24/7, ensuring quick response within 48 hours. Spare parts can be delivered globally, minimizing downtime and maintaining operational efficiency.
With its compact design, powerful performance, and versatile features, the 4T spider crawler crane is an ideal choice for customers seeking a reliable and efficient lifting solution across various industries.
A: We are a professional manufacture , we have our own R&D team and sales team, we provide one-stop service.
A: Yes, offer us necessary information, we provide custom-make service to meet different needs of global clients with different budgets.
A: Yes, we support mass production. We can support customization (one piece is enough), but we can’t provide free samples.
A: Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish Other customizable options
